Hint: Scrap plywood can be glued in place of the masking tape to the fixture to align rods.
Apply AeroPoxy into the front hole allowing glue to flow on
to the leading edge of the stab. Also, fill the hole and area
between the root rib and fiberglass skin for increased
bonding strength. Wipe excess glue.
Insert the taped CF pin into the front hole. Tape the rear spar
to hold in position, and allow AeroPoxy to cure.
Use AeroPoxy to glue the molded CF anti rotation pin
receptacle to the inside of the fuselage. Align the
stabilizers such that the leading edges are in line with
the dots on the fuselage. A 6-32 bolt is used to secure
the front pin.
NOTE: This procedure is repeated for both stabs and the vertical fin.
Setscrews tightened through holes in bottom of the fuselage.
