BYD S1 EV - A;C Operation Panel and Interface (if Fitted)

5
Interior device
5-2 Air conditioning
175
A/C operation panel and interface (if fitted)
Fan speed down button (Reduce
fan speed by one level)
Fan speed up button (Increase fan
speed by one level)
A/C compressor button
A/C air vent mode button
(Switch over among defroster,
instrument, floor, instrument/floor,
and floor/defroster vent modes.)
Internal/external recirculation mode button
A/C ON/OFF button
Temperature adjustment knob (Rotate towards red to increase A/C temperature
setting and rotate towards blue to reduce A/C temperature setting).
A/C display interface
Tip

A/C abnormal smell symptom:

Upon the turn-on of A/C, the airflow outputted by the A/C probably contains a
moist and moldy smell. It’s a normal symptom that the A/C outputs an abnormal
smell. During the working of A/C, the evaporator will be easily adhered with A/C
condensates and the wet evaporator will also be easily adhered with the
non-filtered passenger sweats and dusts. If the condensates on the evaporator
are not blown dry, the molds will easily breed on the dark and moist evaporator
surfaces and the long-time fermentation of molds will easily generate abnormal
smell.

Method for prevention of A/C abnormal smell:

Before stopping the vehicle, turn off the A/C and run under ventilation mode to
maintain relatively dry.

Periodically check, clean, or replace filter screen.

Keep the inside of vehicle compartment clean and fresh.

If the abnormal smell is always present after taking the method for prevention of
abnormal swell, it’s recommended to contact a BYD Auto Authorized Service Station
for repairs.
