2.5.6 12V DC Input
Function:
Input connector for the Desktop digitizer 12V main power supply from the external AC/DC
adapter.
Mechanical specifications:
RAPC722X PCB DC Power Jack.
2.5.7 SPARE Link
Function:
Auxiliary connector reserved for CAEN usage.
Mechanical specifications:
3M-7610-5002 connector.
2.6 Other Front Panel Components
2.6.1 Diagnostic LEDs
The front panel hosts the following LEDs:
Table 2.2: Front panel LEDs
Name:
Colour:
Function:
CLK IN
green
Indicates that the external clock is enabled
TTL
green
Indicates that the standard TTL is set for GPO, TRG-IN and GPI
NIM
green
Indicates that the standard NIM is set for GPO, TRG-IN and GPI
LINK
green/yellow
Network present; Data transfer activity
USB
green
The right green LED indicates the network presence; the left yellow LED signals the data
transfer activity
PLL LOCK
green
Indicates that the PLL is locked to the reference clock
PLL BYPS
green
NOT USED
RUN
green
Indicates that the acquisition is running (data taking)
TRG
green
Indicates that the trigger is accepted
DRDY
green
Indicates that the event/data is present in the Output Buffer
BUSY
red
Indicates that all the buffers are full for at least one channel
