During the acquisition, data stream is continuously written in a circular memory buffer. When
the trigger occurs, the digitizer writes further samples for the post trigger and freezes the buffer
that can be read by one of the provided readout links. The acquisition can continue without any
dead time in a new buffer
DT5740 features a front panel CLK-IN connector as well as an internal PLL for clock synthesis
from internal/external references. Multiple DT5740 boards can be synchronized to a common
clock source ensuring Trigger time stamps alignment. The fan-in of an external clock signal to
each CLK-IN is required. Once synchronized, all data will be aligned and coherent across the
multi-board system.
The module houses USB 2.0 and Optical Link interfaces. USB 2.0 allows data transfers up to 30
MB/s. The Optical Link (CAEN proprietary CONET protocol) supports transfer rate of 80 MB/s and
offers Daisy chain capability. Therefore, it is possible to connect up to 8 ADC modules to a single
A2818 Optical Link Controller, or up to 32 using a A3818 (4-link version). Optical Link and USB
accesses are internally arbitrated.
Table 1.1: Available items
Code
Description
WDT5740XAAAA
DT5740 - 32 Ch. 12 bit 65 MS/s Digitizer: 192kS/ch, EP3C16, SE
WDT5740CXAAA
DT5740C - 10Vpp input 32 Ch 12 bit 65MS/s Digitizer: 192kS/ch, EP3C16, SE
WDT5740DXAAA
DT5740D - 32 Ch. 12 bit 62.5 MS/s Digitizer: 192kSch, EP3C40, SE
WFWDPPQDCAAA⁽*⁾
DPP-QDC- Digital Pulse Processing for Time Stamped Digital QDC (x740)
⁽*⁾ Multi-license packs are also available. Please, refer to the Digitizer web page for the
relevant ordering options.
WA746EXAAAAA
A746E - 32 Ch. Adapter for Lemo connector
WA654XAAAAAA
A654 - Single Channel MCX to LEMO Cable Adapter
WA654K4AAAAA
A654 KIT4 - 4 MCX TO LEMO Cable Adapter
WA2818XAAAAA
A2818 - PCI Optical Link
WA3818AXAAAA
A3818 - PCIe 1 Optical Link
WA3818BXAAAA
A3818 - PCIe 2 Optical Link
WA3818CXAAAA
A3818 - PCIe 4 Optical Link
WA318XAAAAAA
A318 - Cable Adapter Single Ended to Differential
WAI2730XAAAA
AI2730 - Optical Fibre 30 m. simplex
WAI2720XAAAA
AI2720 - Optical Fibre 20 m. simplex
WAI2705XAAAA
AI2705 - Optical Fibre 5 m. simplex
WAI2703XAAAA
AI2703 - Optical Fibre 30cm. simplex
WAY2730XAAAA
AY2730 - Optical Fibre 30 m. duplex
WAY2720XAAAA
AY2720 - Optical Fibre 20 m. duplex
WAY2705XAAAA
AY2705 - Optical Fibre 5 m. duplex
