Document type:

Title:

Revision date:

Revision:

User's Manual (MUT)

Mod. DT5740 32 Channel 12bit - 65MS/s Digitizer

04/05/2016

NPO:

Filename:

Number of pages:

Page:

00100/09:5740x.MUTx/12

DT5740_REV12.DOC

ADC & MEMORY

CONTROLLER

Altera Cyclone EP3C16 or EP3C40 (DT5740D only)

One FPGA serves 16 channels

COMMUNICATION

INTERFACE

Optical Link

CAEN CONET proprietary protocol

Up to 80 MB/s transfer rate

Daisy chainable: it is possible to

connect up to 8 or 32 ADC modules

to a single Optical Link Controller

(respectively A2818 or A3818)

USB

USB 2.0 compliant

Up to 30 MB/s transfer rate

DPP FW SUPPORTED

DPP-QDC firmware for the Charge to Digital Conversion supported only by DT5740D version

FIRMWARE UPGRADE

Firmware can be upgraded via USB/Optical Link

SOFTWARE

General purpose C libraries, configuration tools, readout software (Windows and Linux

support)

POWER CONSUMPTIONS

1.9 A @ 12V (Typ.)
