Us e r 's GU i d e — 35
6BF
FPT
$
0.006 INCH
2. Enter the Tool Diameter:
1d
DIA
$
1. INCH
3. Enter Cut Depth:
.1gC
(Cut Depth) DEPTH
$
0.1 INCH
4. Calculate the adjusted Feed per Tooth:
C
ADJST 0.0100 INCH
5. Calculate the Radial Chip Thinning Factor:
C
RCTF 1.6667 INCH
C
DIA
$
1. INCH
C
FPT
$
0.006 INCH
cuTTINg FEED
advances during one revolution of the spindle, typically measured
Cutting Feed – Based on Feed per Tooth and # of Teeth
0.005 Inch and 4 Teeth:
KEYSTROKE DISPLAY
OO
0.
1. Enter the Feed per Tooth:
5BF
FPT
$
0.005 INCH
2. Enter the Number of Teeth:
4#
TEETH
$
4.
(cont’d)
KEYSTROKE DISPLAY
