Us e r 's GU i d e 47
t
(Min. External Pitch Diameter)
PTCH- SIZE 0.2225 INCH
t
(Max. External Major Diameter)
MAJR+ SIZE 0.2490 INCH
t
(Min. External Major Diameter)
MAJR- SIZE 0.2425 INCH
t
(Max. External Minor Diameter)
MINR+ SIZE 0.2065 INCH
Metric Thread Size


Note: The default Metric Tolerance Class is 6H (Internal). To view
the current Tolerance Class, press
gb
after entering the desired
Metric Thread Size. To change the class, press
b
again.
KEYSTROKE DISPLAY
g
*
ALL CLEAREd
1. Set Tolerance Class to Internal 4H:
4gb
(Thread Class) INT MM 4H
2. Enter the Thread Size:
5mt
SIZE 5. – MM
3. Enter the Thread Pitch and store the nal Thread Size:
0.75t
THRED SIZE
$
5. – 0.75 MM
4. Find the available Internal Thread characteristics:
t
(Cut Tap Drill Size)
TAP DRILL SIZE 4.25 MM
t
(Roll Tap Drill Size)
R-TAP DRILL SIZE 14
t
(Close Fit Drill Size)
CLOSE DRILL SIZE 5.3 MM
t
(Free Fit Drill Size)
FREE DRILL SIZE 5.8 MM
t
(Min. Internal Pitch Diameter)
PTCH- SIZE 4.5130 MM
t
(Max. Internal Pitch Diameter)
PTCH+ SIZE 4.5605 MM
t
(Min. Internal Minor Diameter)
MINR- SIZE 4.1880 MM
t
(Max. Internal Minor Diameter)
MINR+ SIZE 4.3060 MM
(cont’d)
KEYSTROKE DISPLAY
