40 — Ma c h i n i s t ca l c ™ Pr o
DrIll POINT
120gD
KEYSTROKE DISPLAY
OO
0.
1. Enter the Drill Size:
1/2D
1/2
DRILL SIZE $
0.5000 INCH
2. Enter 118° Angle and calculate the Drill Point Cut Depth:
118gD
(Drill Point) DEPTH DRILL
.0.1502 INCH
D ANGLE DRILL $
118.°
D
1/2
DRILL SIZE $
0.5000 INCH
3. Enter 127° angle and calculate the Drill Point cut length:
127gD
(Drill Point) DEPTH DRILL $
0.1246 INCH
THrEaD SIzINg
The
t
key allows you to enter a numeric, fractional or metric
Thread characteristics, as shown in the tables provided later in
this section.
When using the
t
t
key will
O
stores the Thread
