Calculated Industries 4087 - Fractional Thread Size

46 — Ma c h i n i s t ca l c ™ Pr o
Fractional Thread Size


KEYSTROKE DISPLAY
g *
ALL CLEAREd
1. Verify Thread Class is set to 2B:
gb
(Thread Class) INT 2B
2. Enter the Thread Size:
1/4t
SIZE 1/4 – INCH
3. Enter the TPI and store the nal Thread Size:
28t
THRED SIZE $ 1/4 –
28
INCH
4. Find the available Internal Thread characteristics:
t
(Cut Tap Drill Size) TAP DRILL SIZE 3
t
(Roll Tap Drill Size) R-TAP DRILL SIZE 5.9 MM
t
(Close Fit Drill Size) CLOSE DRILL SIZE F
t
(Free Fit Drill Size) FREE DRILL SIZE H
t
(Min. Internal Pitch Diameter) PTCH- SIZE 0.2268 INCH
t
(Max. Internal Pitch Diameter) PTCH+ SIZE 0.2311 INCH
t
(Min. Internal Minor Diameter) MINR- SIZE 0.2110 INCH
t
(Max. Internal Minor Diameter) MINR+ SIZE 0.2200 INCH
t
(Min. Internal Major Diameter) MAJR- SIZE 0.2500 INCH
5. Switch to Thread Class 2A and nd the available External
Thread characteristics:
gbb
(Thread Class) EXT 2A
t
THRED SIZE $ 1/4 –
28
INCH
t
(Rod Size for Thread Cutting) ROD SIZE 0.2500 INCH
t
(Rod Size for Cold Forming) CFORM SIZE 0.2239 INCH
t
(Max. External Pitch Diameter) PTCH+ SIZE 0.2258 INCH
