01/2012
© CAME cancelli automatici s.p.a. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.a. to notify said changes.
ENGLISH
AF card
Connect RG58 antenna cable to the apposite terminals.
Antenna
Plug in the radio-frequency card onto the electronic board AFTER CUTTING OFF THE MAIN POWER SUPPLY (and disconnecting the emer-
gency batteries).
N.B.: The electronic card recognises the radio-frequency card only when it is powered up.
Radio frequency card
Transmitters
see instruction sheet in the packaging
of the AF43SR radi-frequency card
Frequency-MHz Card
Radiofrequency
Serie
transmitters
FM 26,995 AF130 TFM
FM 30.900 AF150 TFM
AM 26.995 AF26 TOP
AM 30.900 AF30 TOP
AM 40.685 AF40 TOUCH
AF43S / AF43SM TAM / TOP
AF43SR ATOMO
AF43S / AF43TW TWIN
AM 868.35 AF868 TOP
Activating the radio command
