Canon 1180 - Sequence of Operations (Jam Detection)

COPYRIGHT © 2002 CANON INC. CANON CLC1100/1130/1150/1160/1180 REV.1 FEB. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)
7-47
CHAPTER 7 PICK-UP / FEEDING SYSTEM
B. Sequence of Operations (jam detection)
A4/LTR, 1 Copy, Full-Color, Direct, Cassette 1
Figure 7-602
Photosensitive drum revolution
Transfer drum revolution
Side A sensor (PS2)
Side B sensor (PS3)
Laser
Registration sensor (PS70)
Transfer blade
Post-transfer paper sensor (PS6)
Pre-cleaning paper sensor (PS71)
Pre-transfer paper sensor (PS5)
Separation sensor (PS7)
Internal delivery sensor (PS12)
External delivery sensor (PS31)
DSRDY
ended
Delay jam check (normal if copy paper is present)
Stationery jam check (normal if copy paper is absent)
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
INTR COPY LSTR
STBY
DSRDY
M M C C Y Y K K
Transfer B M Transfer B C Transfer B Y Transfer B K
