CHAPTER 13 TROUBLESHOOTING
C. I/O (I/O display mode)
The Level 2 screen of I/O mode looks like the following, and it provides the items shown on the
next page.
DC-CON
R-CON
DC-CPU input/output port
R-CPU input/output port
Figure 13-713
Guide to Screens
P001 xxxxxxxxxxxxxxxx
bit 0
bit 15
address
