Canon DC10 E - Disassembly of Rear Cover Unit

DC10 E, DC20 E
DISASSEMBLING
51
1-28 Disassembly of Rear Cover Unit - 3
(1) Detach the Slide SW Knob, the Rear SW Knob, the DP Window, the Menu SW Knob, and the Card Access Window.
Fig. 48
(1)
(1)
(1)
(1)
(1)
Card Access Window
DP Window
Menu SW Knob
Rear SW Knob
Rear Cover
Slide SW Knob
