Canon DC10 E - CCD Image Adjustment (Low Temperature)

DC10 E, DC20 E
SERVICE MODE / ADJUSTMENT
20
5-2-6 CCD Image Adjustment (Low Temperature)
For this adjustment, use the same conditions as those specified in 5-2-2 Iris Adjustment (Coarse Adjustment)
SPEC. Automatic writing
Procedure)
(1) Carry out CCD image adjustment (low temperature) in the following procedure.
STEP PROCEDURE Microcomputer operation
CCD IMAGE ADJUSTMENT CS Function MD ADDR DT
1 1) Make the setting shown at right. 2 08 ST 3013 -- Image adjustment (low temperature)
2) Perform storing.
↑↑
RD
↑↑
Adjustment is completed.
(press the PAUSE button.) Completion with ST:05, NG with ST:09
2 1) Make the setting shown at right. 2 08 ST 3014 -- Adjustment data writing.
2) Perform storing.
↑↑
RD
↑↑
Adjustment is completed.
(press the PAUSE button.) Completion with ST:05, NG with ST:09
