Canon DC10 E - Data Writing

DC10 E, DC20 E
SERVICE MODE / ADJUSTMENT
33
5-6-4 WB Adjustment (2)
CHART Light box (5600°K), and CCA12 filter
SPEC. Automatic adjustment
Procedure)
(1) Referring to the table shown below, carry out WB adjustment (2).
5-6-5 WB Adjustment (3)
CHART Light box (5600°K)
SPEC. Automatic adjustment
Procedure)
(1) Referring to the table shown below, carry out WB adjustment (3).
5-6-6 Data Writing
SPEC. Data writing
Procedure)
(1) According to the table shown below, write adjustment data (5-6-1 to 5-6-5) into the Flash.
STEP PROCEDURE Microcomputer operation
WB (3) CS Function MD ADDR DT
1 1) Make the setting shown at right. 2 08 ST 3005 --
2) Perform storing.
↑↑
WR
↑↑
Adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑↑
Adjustment is completed.
Completion with ST:05, NG with ST:09
MONITOR
STEP PROCEDURE Microcomputer operation
EEPROM WRITING CS Function MD ADDR DT
1 1) Make the setting shown at right. 2 08 ST 3006 00
2) Perform storing.
↑↑
RD
↑
-- Completion of Flash writing.
(press the PAUSE button.) Completion with ST:05, (NG with ST:09)
MONITOR
STEP PROCEDURE Microcomputer operation
WB (2) CS Function MD ADDR DT
1 1) Make the setting shown at right. 2 08 ST 3004 --
2) Perform storing.
↑↑
WR
↑↑
Adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑↑
Adjustment is completed.
Completion with ST:05, NG with ST:09
MONITOR
