Canon DC10 E - Current Consumption Check

DC10 E, DC20 E
SERVICE HINTS
5
1-3 Current Consumption Check
The following table shows the specified value of current consumption in each status.
Measurement condition : Product status, DVD-RW (Video mode), recording mode : XP, camera auto mode (AF OFF), LCD ON
(Approx. 0.03A each smaller in the case of CVF)
Preset voltage : 7.4V
DC10 E
DC20 E
POWER SW MODE Current consumption (A)
CAMERA REC PAUSE 0.47
REC 0.84
PLAY PLAY (DISC) 0.71
PLAY (CARD) 0.40
POWER OFF 0.79 (mA)
POWER SW MODE Current consumption (A)
CAMERA REC PAUSE 0.55
REC 0.93
PLAY PLAY (DISC) 0.76
PLAY (CARD) 0.45
POWER OFF 0.71 (mA)
