Canon DC10 E - Functional Check of Control Keys and Switches; CCM MI-COM Input Port; CCM MI-COM A;D Port; SUB MI-COM Input Port

DC10 E, DC20 E
SERVICE MODE / ADJUSTMENT
10
4-4 Functional Check of Control Keys and Switches
<Outline>
(1) The CCM and SUB MI-COM terminals can be checked in the service mode. With this function, the key-related operations and the
connections between the keys and the MI-COM terminals can be checked in the product state.
(2) Perform the check in the RD mode.
4-4-1 CCM MI-COM Input Port
4-4-2 CCM MI-COM A/D Port
4-4-3 SUB MI-COM Input Port
4-4-4 SUB MI-COM A/D Port
PIN NAME Description CS Function ADDR
DAT
A
BIT
Description
E13 CARD DET Detection memory card loading 1 01 0014 5 "L" for memory card
loading
U13 START STOP Start / Stop SW 1 01 000E 4 "L" at the ON time
T13 Half Photo Switch Halfway pressing of Photo SW 1 01 000E 5 "L" at the ON time
R13 Photo Switch Full pressing of Photo SW 1 01 000E 6 "L" at the ON time
Low High
C6 KEY AD3 KEY AD 3 1 02 0005 UP(00) DOWN(40) SET(80) MENU(C0)
B6 KEY AD2 KEY AD 2 1 02 0004 RIGHT(00) LEFT (40) PRINT(80) FUNC(C0)
A6 KEY AD1 KEY AD 1 1 02 0003
C5 KEY AD0 KEY AD 0 1 02 0002
E8 ZOOM KEY Zoom key output 1 02 0016 WIDE CENTER TELE
A8 I ENC IRIS ENC output 1 02 0014 Small diaphragm Open
B7 Y GYRO Yaw GYRO output 1 02 0011
A6 P GYRO Pith GYRO output 1 02 0010
C3 MODE DIAL 1 AE Mode (SCN) 1 02 000A SCN (00)
A4 MODE DIAL 0 AE Mode (P) 1 02 000B P (00
）
REW (00) FINAL(40) B.L (80) W.TV(C0)
AD DATA (00
〜
FF)
Function ADDR
STOP (00) PLAY (40) FF (80) DISP(C0)
PIN NAME Description CS
PIN NAME Description CS Function ADDR
DAT
A
BIT
Description
21 Movie/Still SW Movie/Still SW 1 1E 0005 4 "H" at Movie
12 DC J DET DC JACK detection 1 1E 0004 2 "H" at the setting
20 Eject Switch EJECT SW detection 1 1E 0005 5 "L" at the ON time
25 Li3V Detect Detection of decrease in lithium 1 1E 0004 1 "L" at thedecrease
battery voltage
32 CAM Power Switch POWER SW detection 1 1E 0006 7 "L" at the ON time
33 Power Switch POWER SW detection 1 1E 0006 6 "L" at the ON time
Low High
27 Batt Info A/D Battery Temperature Detection 1 1E 0001 High(FF) Low(00)
26 Batt A/D Battery Voltage Detection 1 1E 0000 Low(00) High(FF)
AD DATA (00
〜
FF)
PIN NAME Description CS Function ADDR
