DC10 E, DC20 E
GENERAL DESCRIPTION OF PRODUCT
22
5-12 Built-in microphone Stereo (using electret condenser microphone)
Omni-directional microphone × 2 + Electric circuitry for stereo
5-12-1 Wind screen function Included. With ON/OFF switch (Menu selection. Available for built-in microphone only)
5-13 Built-in Flash Shooting (DC20 E only) Pre-flash light adjustment system
5-13-1 Flash modes Auto flash, auto flash with red-eye reduction, manual flash, flash off
5-13-2 Shutter speed Flash On : Flash at 1/1000 sec or less in Movie mode and at 1/500 sec or less in Still Image mode.
5-13-3 Shooting distance Wide end, approx. 80 cm to 2.5 m, Tele end, approx. 1 m to 1.3 m
The allowable shooting range is indicated as approx. 1 to 2 m in the Instruction Manual.
5-14 Auxiliary light source (DC20 E only) Includes mini video light (equipped with high-brightness white LED) with light button.
Enables shooting at distances of approx. 1.5 m in AUTO mode.
5-14-1 Flash mode The AF auxiliary light is set to Auto when AF Auxiliary Auto is selected and when red-eye
reduction function is selected. The AF auxiliary light is OFF in Fireworks mode.
5-15 Other additional functions
5-15-1 Disc counter The total cumulative time for a recoding scene is indicated by hours: minutes: seconds.
5-15-2 Data code The date and camera information during recording are automatically recorded and can be dis-
played during playback.
a. Time and date Automatic calendar range: January 1, 2005 through December 31, 2030 (the initial setting is
January 1, 2005)
The recording start (year/month/day) display can be selected from the three options below:
Supports world clock (Selecting the city name of your destination automatically adjusts to the
date and time of the destination. Supports daylight saving time), and records the recording start
time (hour/minute/second).
b. Camera data Shutter speed and aperture value information are recorded (but not displayed during recording),
and can be displayed during playback. During playback, time can be displayed in five different
modes (date only, time only, date and time, or date and time and camera data).
5-15-3 Accessory shoe Not supported
5-15-4 REC Search function None
5-15-5 REC Review function Supported. Accessed by operating the Recording Check button when camera recording is paused. Plays
back the movie from the beginning of the recorded scene and then returns to the state before playback
started. There is no sound.
5-15-6
Remote control reception ON/OFF
Possible. This can be done in Camera mode and PLAY mode (by selecting from menu).
5-15-7 Headphone volume adjustment Not available (Headphone terminal not included)
5-15-8 Widescreen TV (16:9) When Widescreen TV mode is selected (button setting), the LCD panel screen changes to letterbox
display (top and bottom of the screen are masked with black bands). Setting is possible in
AUTO mode. Widescreen TV cannot be set under VIDEOmode and LP mode
5-15-9 AEB shooting Recording is done in Card/Camera mode with exposure correction automatically changed to ±0
level, -0.5 level, and +0.5 level. (Continuous shooting mode: when AEB is selected) Flash
shooting is not possible.
5-15-10 Still image check time setting After releasing the Photo button, the display time can be set for checking the still images.
One of 6 settings; OFF (0 sec), 2, 4, 6, 8, or 10 seconds can be selected as the setting mode.
5-15-11 Microphone attenuation No function
5-15-12 Microphone level meter No function
5-15-13 Image effect settings The available image effect settings in the FUNC. menu are Vivid, Neutral, Low Sharpening, Soft
Skin Detail, and Custom. These settings cannot be made in Special Scene mode.
Vivid Emphasizes contrast and color depth, and presents images with vibrant and striking colors.
Neutral Limits the contrast and color depth, and presents pure images without any enhancements.
Low Sharpening Provides image with less distinct outlines and a softer touch.
Soft Skin Detail Smoothes the outlines of skin sections, and presents skin sections with a softer tone.
Custom Enables adjustment of the brightness, contrast, sharpness, and color depth.
