DC10 E, DC20 E
TECHNICAL DESCRIPTION
2
USB section
• IC3500 USB IC USB I/F
(2) SUB PCB
• IC1501 CVF DRIVER CVF signal processing and drive
• IC1502 2.8V REGULATOR 2.8V regulator
• IC801 AIF4 Analog input/output signal processing, speaker amplifier
(3) CCD PCB
• IC1050 (DC20 E) INVERTER CCD horizontal transfer pulse inverter
• IC1051 (DC20 E) INVERTER CCD horizontal transfer pulse inverter
• IC1052 (DC20 E) INVERTER CCD horizontal transfer pulse inverter
• IC1053 (DC20 E) INVERTER CCD horizontal transfer pulse inverter
• IC1054 (DC20 E) CCD CCD image sensor
• IC1055 (DC20 E) OPE AMP CCD output amp
• IC1070 (DC10 E) CCD CCD image sensor
• IC1071 (DC10 E) BUFFER CCD horizontal transfer pulse buffer
• IC1072 (DC10 E) BUFFER CCD horizontal transfer pulse buffer
(4) LCD PCB
• IC901 EEPROM EEPROM for LCD data
• IC902 LCD DRIVER LCD signal processing and drive
• IC903 2.8V REGULATOR 2.8V regulator
(5) GYRO PCB
• IC1603 P SENSOR GYRO Pitch-direction angular speed detection
• IC1604 Y SENSOR GYRO YAW-direction angular speed detection
(6) FLASH PCB (DC20 E only)
• IC501 DC/DC CONVERTER CONTROL Control for main capacitor charging
(7) CVF PCB
Signal transfer from the SUB PCB to the CVF, CVF Backlight LED
(8) DC JACK PCB
DC JACK
(9) CARD PCB
Memory card slot, lithium secondary battery
(10) AV FPC
Multi JACK
(11) USB FPC
USB JACK
(12) TS MACH
FRONT END (Pickup, spindle, control PCB)
