DC10 E, DC20 E
TECHNICAL DESCRIPTION
13
<CCD> IC1070
• 1/4-inch interlaced CCD
• Complementary color filter
• Total number of pixels : Approx. 1,330,000
Effective number of pixels : Tape : Approx. 690,000
: Tape : Approx. 1,230,000
<CDS/AGC/AD/TG/V-DRIVER> IC1002
A signal read out of the CCD is extracted. Then, after the extracted signal is subjected to AGC processing and A/D conversion, it
is output as a digital signal.
<DIGIC DV> IC1103
This circuit carries out various camera signal processing operations (EIS, AWB, etc.) and digital effect processing. It also performs
multimedia-application signal processing mainly for still image recording.
• Feature engine
• High-speed card interface
• JPEG method compression/extension
• Audio data compression (ADPCM)
• USB function
<SDRAM> IC1101, IC1102
Field memory for camera signal processing and digital effect processing
Image data memory for Memory card write/read operation
