Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 113
Table 77 – Network Environment Wired LAN Specifications
Item Specifications
Network Interface
10Base-T/100Base-TX/1000Base-T (RJ-45)
Protocol Supported
TCP/IP
• Frame type: Ethernet II
• Print applications: LPD/Raw/IPP/IPPS/FTP/WSD/Mopria/
Windows10 Mobile Print
AppleTalk
• Frame type: Ethernet SNAP
• Print application: PAP (Printer Access Protocol)
Table 78 – Network Environment Wireless LAN Specifications
Item Specifications
Standard
IEEE 802.11g, IEEE 802.11b, IEEE 802.11n
Transmission Scheme
IEEE 802.11b (Modulation system: DS-SS)
IEEE 802.11g (Modulation system: OFDM method)
IEEE 802.11n (Modulation system: OFDM method)
Frequency Range
2,412 to 2,472 GHz
Maximum Radio-
Frequency Power
Transmitted
18.21 dBm
Communication Mode
Infrastructure Mode
Access Point Mode
Security
Infrastructure Mode
128 (104)/64 (40) bit WEP
WPA-PSK (TKIP/AES-CCMP)
WPA2-PSK (TKIP/AES-CCMP)
WPA-EAP (AES-CCMP)
WPA2-EAP (AES-CCMP)
Access Point Mode
WPA2-PSK (AES-CCMP)
Wi-Fi Direct Mode
WPA2-PSK (AES-CCMP)
Connection Method
WPS (Wi-Fi Protected Setup), Manual setup
