Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 63
I. Firmware Upgrade
The imagePRESS Lite C170 / C165 devices supports firmware downloads from
the SST (Service Support Tool), USB memory stick and the Content Delivery
System. Refer to the imagePRESS Lite C170 / C165 Service Manual for
details.
1. Service Support Tool
The Service Support Tool
66
(version 4.81 or later) provides a graphical
interface between the PC and the copier. Refer to the SST User Manual.
The SST is available via the e-Support Center Website and provides two
main functions:
a. Flash Upgrade Function
The SST can upgrade the Flash Dual In-Line Memory Modules
(FDIMM) firmware, BootROM, DCON and RCON. The SST is also
capable of downloading to a HDD System, RUI (Remote User
Interface), Key, SDICT, TTS, Browser, ASR, WebDAV, Media, Help
and Language Files. Additionally, the SST can format a HDD and load
software.
The SST Download Progress Monitor
67
is available via the e-Support
Center Website. The tool will enable the service technician to monitor
the download progress of firmware to device.
b. Backup / Restore RAM Data
If replacing any PCBs with FDIMMs attached or initializing RAM, the
SST can be used to create a backup of the FDIMM RAM data and
saved to a PC. Once the PCB has been replaced, the RAM backup file
can be restored to the imagePRESS device and factory settings
restored.
2. Content Delivery System
The CDS is Canon’s next generation system for the delivery and
installation of firmware to the imagePRESS Lite C170 / C165 with the
imagePRESS Server attached. Refer to the Content Delivery System on
page 60.
IMPORTANT
Content Delivery System only supports TLS V1.2 and earlier.
66 Check the e-Support Center Download Center for the most current version of the Service Support Tool
67 Check the e-Support Center Download Center for the most current version of the SST Download Progress Monitor.
