B. Installation Dimensions & Weight
The imagePRESS Lite C170 / C165 approximate weight and dimensions differ
depending on its configuration with the optional accessories. The dimensions
are for reference only and should not be confused with the required space for
installation.
Table 21 – Dimensions
Unit Width Depth Height
Main Unit 27 1/8” 689 mm 37 1/8" 941 mm 48” 1,220 mm
Main Unit (Including the Upright
Control Panel)
58 7/8” 1,495 mm 37 1/8" 941 mm 55 1/4” 1,403 mm
POD Deck Lite-C1 25 7/8" 656 mm 27” 686 mm 22 1/2” 570 mm
Paper Deck Unit-E1 14 1/4" 363 mm 24 7/8” 630 mm 22 1/2” 572 mm
Staple Finisher-W1 PRO
58, 59
31 1/2” 800 mm 31 1/4” 792 mm 48 3/4” 1,239 mm
Booklet Finisher-W1 PRO
58, 59
31 1/2” 800 mm 31 1/4” 792 mm 48 3/4” 1,239 mm
Document Insertion Unit-N1 29 3/8” 746 mm 31 1/4" 793 mm 55 3/8” 1,407 mm
Paper Folding Unit-J1
13 1/4" 336 mm 31 1/4" 793 mm 46 7/8” 1,190 mm
Booklet Trimmer-F1
60
82 1/2" 2,095 mm 31 1/8" 790 mm 41” 1,040 mm
Multi Function Professional
Puncher-B1
17 1/2" 445 mm 31 3/8" 795 mm 41” 1,040 mm
Puncher Unit-BS1
Puncher Unit-BT1
Inside the Staple Finisher-W1 PRO /
Booklet Finisher-W1 PRO
Staple Finisher-AC1
61, 62
47 1/8” 1,195 mm 25 7/8” 656 mm 24 1/4” 623 mm
Booklet Finisher-AC1
61, 62
47 1/8” 1,195 mm 25 7/8” 656 mm 24 1/4” 623 mm
Document Insertion / Folding
Unit-K1
48 7/8” 1,242 mm 26 1/8” 662 mm 26 3/4" 679 mm
2/3-Hole Puncher Unit-A1
Inside the Staple Finisher-AC1 /
Booklet Finisher-AC1
Jogger Kit-A1
Copy Tray-R2 6 7/8” 175 mm 16 1/2" 420 mm 15” 382 mm
Copy Card Reader-F1 1 5/8” 40 mm 3 1/2” 88 mm 3 3/4" 96 mm
58 When the auxiliary tray is extended
59 When the Long Sheet Tray-B1 is attached and extended: the width is 44 3/4" (1,136 mm)
60 With the delivery tray is extended.
61 When the auxiliary tray and rotation tray are extended.
62 When the Long Sheet Tray-B1 is attached and extended: the width is 30 1/2" (774 mm).
