D. Estimated Installation Times
The table below indicates the estimated length of time needed to unpack and
install the main unit and optional accessories, calculated from the average
amount of labor hours. The estimated unpack and installation times are based
on a minimum of one (1) experienced technicians unless otherwise specified.
IMPORTANT
Setup time varies due to many factors, most of which the installation technician
has little control over. Some obstacles may include:
• Forklift availability and its operator
• Narrow hallways or a need to remove doors to enter rooms
• Uneven or damaged floors making leveling equipment difficult and time
consuming
With the above-mentioned obstacles considered, an installation of
imagePRESS Lite C170 / C165 Main Unit can take longer than the estimated
total times below.
Table 26 – Estimated Installation Times
Description
Estimated
Total Time
imagePRESS Lite C170 / C165 Main Unit
63
42 minutes
Stamp Unit-B1 3 minutes
Printer Cover-H1 27 minutes
NFC Kit-A1 (for Upright Control Panel)
NFC Kit-C1 (Flat Control Panel) 14 minutes
Upright Control Panel-H1 34 minutes
Paper Deck Unit-E1 9 minutes
POD Deck Lite-C1 16 minutes
Long Sheet Feeding and Catch Tray-B1 7 minutes
Long Sheet Catch Tray XL-A1 9 minutes
Stack Bypass Alignment Trat-D1
Copy Tray-R2 4 minutes
Staple Finisher-W1 PRO 17 minutes
Staple Finisher-AC1 12 minutes
Booklet Finisher-AC1 13 minutes
Document Insertion Unit-N1
2/3 Hole Puncher-A1 8 minutes
63 Installation time includes the DADF
To Next Page
