Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 14
E. POD Deck Lite-C1
• Provides an additional paper capacity of approximately 3,500 sheets
(80 g/m
2
) or 3,660 sheets (75 g/m
2
)
• Supports paper sizes up to 11” x 17”
• Supports paper weights up to 130 lb Cover (350 g/m
2
)
• Cannot be installed with the Paper Deck Unit-E1
Note: The Registration Plate-A1 is included with the POD Deck Lite-C1. To
achieve the rated registration and optimal performance, Installation the
Registration Plate with the POD Deck Lite.
IMPORTANT
The imagePRESS Lite C170 / C165 supports the POD Deck Lite-C1 with a
serial number SZK10000 or later.
F. Long Sheet Catch Tray XL-A1
• Formerly named the Finisher Long Sheet Catch Tray-A1.
• A long sheet extension tray that attaches to the Staple Finisher-W1 PRO
or Booklet Finisher-W1 PRO.
• Manual handling is not required to retrieve printed sheets from the Finisher.
• Supports paper weights up to 130 lb cover (350 g/m
2
).
• Supports approximately 50 sheets with a length between 30” up to 51.2”.
• Supports approximately 300 sheets with a length between 19.2” up to 30”.
G. Long Sheet Feeding and Catch Tray-B1
• Formerly named the Long Sheet Tray-B1.
• Includes 2 sets of long sheet extension wires for the Stack Bypass
Alignment Tray-D1, a Finisher (Staple Finisher-W1 PRO, Booklet Finisher-
W1 PRO, Staple Finisher-AC1 or Booklet Finisher-AC1), or Copy Tray-R2.
• Input tray capacity of up to one (1) sheet.
• Supports paper weights up to 130 lb cover (350 g/m
2
).
• Supports sheet size lengths up to 51.2”.
Note: Long sheets between 30” up to 51” may require manual handling to input
sheets into the engine and retrieve printed sheets from the Finisher.
H. Copy Tray-R2
• Simple Tray for Basic output
• 100-sheet output capacity
• Cannot be installed with the Staple Finisher or Booklet Finisher
I. Tab Feeding Attachment Kit-F1
• Enables printing on tab paper from Paper Cassette 2.
