Canon imagePRESS Lite C170 - Document Insertion Unit-N1; Paper Folding Unit-J1; Booklet Trimmer-F1; Multi Function Professional Puncher-B1

Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 17
S. Document Insertion Unit-N1
• Inserts pre-printed cover sheets or insertion sheets for binding.
• The upper paper feed tray and lower paper feed tray have a capacity of up
to 200 sheets each (total 400 sheets) (20 lb bond (80 g/m
2
)).
• Supports paper weights up to 110 lb cover (300 g/m
2
)
• Requires the Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO.
T. Paper Folding Unit-J1
• Provides support to Z-fold, Inner C-fold, Outer C-fold, and Half-fold
documents up to 28 lb bond (105 g/m
2
).
• Supports paper sizes up to 11” x 17”.
• Requires the Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO.
U. Booklet Trimmer-F1
• Provides adjustable front trimming of saddle-stitched booklets of up to
25-sheets (approximately 100 pages).
• The Conveyor Tray can hold approximately 30 booklets.
• Connects to the Booklet Tray of the Booklet Finisher-W1 PRO.
V. Multi Function Professional Puncher-B1
• Provides a variety of punch patterns, which are available as die sets
(replaced by the end-user).
• Provides the end-user the ability to create off-line plastic spiral bound
books.
• Supports paper sizes up to 13” x 19”.
• Supports paper weights up to 130 lb Cover (350 g/m
2
).
• Requires the Staple Finisher-W1 PRO or Booklet Finisher-W1 PRO.
• Supports Double Punch on LTRR and 11” x 17” paper sizes. This function
is supported for several dies, and paper weights 20 lb Bond to 110 lb Cover
(75 g/m
2
to 300 g/m
2
) plain or 31 lb Bond to 110 lb Cover (118 g/m
2
to 300
g/m
2
) coated.
IMPORTANT
• The Multi Function Professional Puncher requires a firmware upgrade to
use the Double Punch feature.
• The Service Technician Enables the Double Punch feature on the Multi
Function Professional Puncher console.
• Once the Double Punch feature is enabled by the service technician, the
end user can enable or disable the feature on the Multi Function
Professional Puncher console. Once enabled by the end-user the feature
remains enabled until disabled by the end-user.
Note: The Multi Function Professional Puncher-B1 does not support punching
OHP/transparent media.
