O. Consumable Parts
Consumable parts are parts having a limited life that will be reached during a
customer’s specific machine operation, and should then be replaced as
needed. Examples of consumable parts include, but are not limited to, feed
rollers and cleaner blades.
An estimated consumable parts list is provided in the table below to assist in
the initial parts/supplies planning. A consumable part’s life expectancy is
directly related to usage factors, such as paper size, paper quality,
environment, usage application, and machine maintenance. Therefore,
consumable parts do not have a warranty, and Canon USA cannot guarantee
a minimum life.
Note: All consumable parts shown in the table below are for reference
purposes only, and are subject to change without notice.
Table 30 – Main Unit Consumable Parts
Description
Part Number
2
Quantity
Estimated Life
68
Remarks
Developing Assembly (Bk)
FM1-P092-000
1
900,000 pages
71
Specified by
the number of
sheets on a A4
size basis
Developing Assembly (Y)
FM1-P089-000
1
900,000 pages
71
Developing Assembly (M)
FM1-P090-000
1
900,000 pages
71
Developing Assembly (C)
FM1-P091-000
1
900,000 pages
71
Drum Cleaning Blade (Bk)
FC8-2281-000
1
750,000 pages
Specified by
the Running
Distance in
Charged State
Drum Cleaning Scoop-up Sheet (Bk)
FL2-8652-000
1
750,000 pages
Front Edge Scraper (Bk)
FL2-8653-000
1
750,000 pages
Rear Edge Scraper (Bk)
FL2-8654-000
1
750,000 pages
ITB
FM1-W109-000
1
740,000 pages
71
Specified by
the number of
sheets on a A4
size basis
ITB Cleaning Blade
FL1-7724-000
1
370,000 pages
71
Primary Transfer Roller (Y/M/C/Bk)
FC0-2331-000
4
740,000 pages
71
Secondary Transfer Inner Roller
FC7-9325-000
1
740,000 pages
71
Secondary Transfer Outer Roller
FE8-0387-000
1
740,000 pages
71
Secondary Transfer Static Eliminator
FM3-9841-000
1
740,000 pages
71
ITB Inner Scraper
FL1-2173-000
1
740,000 pages
71
Fixing Film Unit
FM1-N742-000
1
390,000 pages
71
Fixing Pressure Roller Unit
FM0-0387-000
1
390,000 pages
71
Fixing Web
FC0-8030-000
1
300,000 pages
71
Fixing Heat Soaking Roller
FC0-7967-000
1
390,000 pages
71
Ball Bearing
XG9-0876-000
2
390,000 pages
71
2 Part numbers are subject to change without notice.
68 Value is based on LTR sized paper. Estimated average values in the field, based on data from
supplier. Data is subject to change depending upon many factors including, without limitation,
monthly copy volume, environment, type of image printed and customer handling of the equipment.
71 Estimated Life is based on the Large Paper Ratio
