Table 35 – Document Insertion Unit-N1 Consumable Parts
Description
Part Number
2
Quantity
Estimated Life
68
Remarks
Upper Tray Pickup roller
4A3-3870-000
1
100,000 sheets
Upper Tray Separation roller
4A3-3868-000
1
100,000 sheets
Upper Tray Feed roller
4A3-3869-000
1
100,000 sheets
Upper Tray Torque limiter
4A3-3888-000
1
1,000,000 sheets
Lower Tray Pickup Roller
4A3-3870-000
1
100,000 sheets
Lower Tray Separation Roller
4A3-3868-000
1
100,000 sheets
Lower Tray Feed Roller
4A3-3869-000
1
100,000 sheets
Lower Tray Torque limiter
4A3-3888-000
1
1,000,000 sheets
Upper Tray Electromagnetic clutch
4H3-0290-000
1
1,000,000 sheets
Lower Tray Electromagnetic clutch
4H3-0290-000
1
1,000,000 sheets
Through-pass inlet antistatic needle
4F8-0048-000
2
6,000,000 sheets
Reversal solenoid assembly
FL2-7191-000
1
1,000,000 sheets
Through-pass outlet antistatic
needle
FL3-3418-000 2 6,000,000 sheets
2 Part numbers are subject to change without notice.
68 Value is based on LTR sized paper. Estimated average values in the field, based on data from
supplier. Data is subject to change depending upon many factors including, without limitation,
monthly copy volume, environment, type of image printed and customer handling of the equipment.
Table 36 – Document Insertion / Folding Unit-K1 Consumable Parts
Description
Part Number
2
Quantity
Estimated Life
68
Remarks
Pickup roller (upper)
4A3-3870-000
1
100,000 sheets
Separation roller (upper)
4A3-3868-000
1
100,000 sheets
Feed roller (upper)
4A3-3869-000
1
100,000 sheets
Torque limiter (upper)
4A3-3888-000
1
1,000,000 sheets
Horizontal Feed Slave Roller
FE3-7671-000
1
2,000,000 sheets
2 Part numbers are subject to change without notice.
68 Value is based on LTR sized paper. Estimated average values in the field, based on data from
supplier. Data is subject to change depending upon many factors including, without limitation,
monthly copy volume, environment, type of image printed and customer handling of the equipment.
