Canon imagePROGRAF iPF710 User Manual

Responding to Messages
55
1.
2.
Remove the roll.
Load the new roll.
3.If no barcode was printed on the
roll, specify the paper type.
There is no more paper left on
the roll.
Follow the steps below to replace the
used roll with a new roll of the same
type and size.
The roll is empty.
Error Messages
Cause
Corrective Action
4.If no barcode was printed on the
roll, specify the paper length.
(→"Removing the Roll from the
Printer," User Manual)
(→"Removing a Roll from the Roll
Holder," User Manual)
(→P.11)
(→"Selecting the Paper Type
(Roll)," User Manual)
(→"Specifying the Paper Length
(Roll)," User Manual)
This type of paper is not
compatible with HP-GL/2.
The printer has received a HP-
GL/2 print job that cannot be
printed on the paper that has
been advanced.
Replace the paper with a type
compatible with HP-GL/2. For details
on paper compatible with HP-GL/2,
refer to the Paper Reference Guide.
(→"Types of Paper," User Manual)
GL2: Wxxxx The memory is
full. (xxxx is 0501, 0903, or
0904)
The printer memory is full. Because the entire print job could not
be received, the printer may not be
able to print the entire original. Check
the printing results.
GL2: W0502 The parameter
is out of range.
A parameter specied in a HP-
GL/2 command is out of the
supported range.
Check the print job.
The printer may continue printing, but
the printing quality may be affected.
Check the printing results.
GL2: W0504 This command
is not supported.
The printer has received
an unsupported HP-GL/2
command.
Check the print job.

Canon imagePROGRAF iPF710 Specifications

Printer Specifications

print resolution (max.)	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm
number of nozzles	Matte Black: 5, 120 Nozzles, Other Colors: 2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print head swath	1.07 inch

Ink Specifications

ink type	Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K); Pigment: Matte Black (MBK) – Two Channels
ink tank capacity	130ml per Color
number of colors	5

Media Specifications

media width (roll feed)	10" – 36" (254mm – 914.4mm)
media width (cut sheet)	8" – 36" (203.2mm – 914.4mm)
printable margins (roll feed)	All Sides: 0.12" (3mm) or 0" for Borderless
minimum printable media length (roll feed)	8.0" (203mm)
maximum print length (roll feed)	59' (18m)
maximum print length (cut sheet)	5.2' (1.6m)
borderless printing widths (roll media only)	10", 14", 16", 24", 36", B2 (20.28"/515mm), A1 (23.38"/594mm), B1 (28.66"/728mm), AO (33.11"/841mm)
media thickness (roll feed)	0.07 – 0.8mm (2.8 – 31.4mil)
media thickness (cut sheet)	0.07 – 0.8mm (2.8 – 31.4mil)
media core sizes	2" or 3" Core (2/3" Core Adapter Included)
maximum roll outer diameter	5.9" (150mm)

Power and Acoustic

power supply	AC 100–240V (50-60Hz)
power consumption (maximum)	140W or Less
power consumption (standby)	5W or Less (10W or less when IEEE1394 is mounted)
power consumption (power off)	1W or Less (Executive Order Compliant)
acoustic noise (operation)	52dB (A) or Less
acoustic noise (standby)	35dB (A) or Less
acoustic power	6.6 Bels or Less

Operating Environment

operational temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (h x w x d)	59.3" x 34.3" x 43.1" / 1507mm x 871mm x 1094mm
weight (with stand)	Approx. 141 lb. / 64kg
