Troubleshooting If You Cannot Print as Expected
67
The back side of the paper
is dirty
The Platen has become dirty
after borderless printing or
printing on small paper.
Open the Top Cover and clean the
Platen.
The Paper Retainer is soiled. Clean the Paper Retainer.
(→"Cleaning the Paper Retainer," User
Manual)
The paper feed amount is not
adjusted correctly.
Adjust the feed amount.
(→P.38)
Selecting Band Joint may improve
printing results.
In the printer menu, Print
Length is specied in Feed
Priority.
Printing does not proceed
smoothly because print jobs are
interrupted during transmission.
Exit other applications and cancel other
print jobs.
Adjust the feed amount in the printer
menu by specifying Band Joint in Feed
Priority and try printing again.
Phenomenon
Cause
Corrective Action
You are using a paper that does
not dry easily.
Specify a time of about a minute in Roll
DryingTime.
The surface of the paper
is dirty
The Paper Retainer is soiled. Clean the Paper Retainer.
(→"Cleaning the Paper Retainer," User
Manual)
The contrast becomes
uneven during printing
The paper feed amount is out of
adjustment.
Adjust the feed amount.
Banding in different colors
occurs
(→P.47)
(→"Adjusting the Feed Amount
Automatically," User Manual)
The Printhead is out of
alignment.
Adjust the Printhead alignment.
(→"Adjusting the Printhead Alignment
Automatically," User Manual)
Streaks may occur if you set the
Print Quality too low.
Choose a higher level of Print Quality
in the Advanced Settings of the printer
driver and try printing again.
(→"Giving Priority to Particular Graphic
Elements and Colors for Printing," User
Manual)
(→P.47)
Execute Fine Band Adj. during printing.
(→"Adjusting the Feed Amount
Automatically," User Manual)

Canon imagePROGRAF iPF710 Specifications

Printer Specifications

print resolution (max.)	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm
number of nozzles	Matte Black: 5, 120 Nozzles, Other Colors: 2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print head swath	1.07 inch

Ink Specifications

ink type	Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K); Pigment: Matte Black (MBK) – Two Channels
ink tank capacity	130ml per Color
number of colors	5

Media Specifications

media width (roll feed)	10" – 36" (254mm – 914.4mm)
media width (cut sheet)	8" – 36" (203.2mm – 914.4mm)
printable margins (roll feed)	All Sides: 0.12" (3mm) or 0" for Borderless
minimum printable media length (roll feed)	8.0" (203mm)
maximum print length (roll feed)	59' (18m)
maximum print length (cut sheet)	5.2' (1.6m)
borderless printing widths (roll media only)	10", 14", 16", 24", 36", B2 (20.28"/515mm), A1 (23.38"/594mm), B1 (28.66"/728mm), AO (33.11"/841mm)
media thickness (roll feed)	0.07 – 0.8mm (2.8 – 31.4mil)
media thickness (cut sheet)	0.07 – 0.8mm (2.8 – 31.4mil)
media core sizes	2" or 3" Core (2/3" Core Adapter Included)
maximum roll outer diameter	5.9" (150mm)

Power and Acoustic

power supply	AC 100–240V (50-60Hz)
power consumption (maximum)	140W or Less
power consumption (standby)	5W or Less (10W or less when IEEE1394 is mounted)
power consumption (power off)	1W or Less (Executive Order Compliant)
acoustic noise (operation)	52dB (A) or Less
acoustic noise (standby)	35dB (A) or Less
acoustic power	6.6 Bels or Less

Operating Environment

operational temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (h x w x d)	59.3" x 34.3" x 43.1" / 1507mm x 871mm x 1094mm
weight (with stand)	Approx. 141 lb. / 64kg
