LASER CLASS 730i/720i/710 Chapter 4: Maintenance and Service
4-54
Figure 4-19 Service Data 5
#4A SPECIAL, #4B NCU, #4C ISDN
The values of these items are all set to match a specific nation’s
communications standards by the #5 TYPE setting. Do not change these
settings.
#6 SCANNER
Tampering with this setting may cause the scanned image quality to
deteriorate. Do not change these settings.
#4B NCU
#4C ISDN
1.TONE/PULSE
2.DIAL TONE
3.2nd DIAL TONE
4.BUSY TONE 0
5.BUSY TONE 1
6.REORDER TONE
7.MULTI
8.AUTO RX
9.CNG DETECT
10.RKEY
11.PBX DIAL TONE
12.PBX BUSY TONE
ISDN BASIC
ISDN G4
ISDN G3
(NCU settings)
(Type setting)
U.S.A.
#5 TYPE
SW01
SW01 to SW30: Not used
SW30
#4A SPECIAL
#6 SCANNER
(Scanner function settings)
1.Bit SW
2.SLICE
3.GAMMA
4.Numeric
5.LUT1 fno
6.LUT2 adj
7.CCD
8.CS TYPE
