LASER CLASS 730i/720i/710 6.NUMERICAL INDEX
6-1
6. NUMERICAL INDEX
PART
NUMBER
FIGURE &
KEY No.
DESCRIPTION
PART
NUMBER
FIGURE &
KEY No.
DESCRIPTION
CK-8006-000 51 - T1 ELECTRICITY GREASE (IF-20)
FG3-1587-000 45 - 1 G3 FAX BOARD PCB ASSEMBLY
FG3-2497-000 45 - 2 DIMM ASS’Y
FG3-2973-000 36 - 1 PCL BOARD ASS’Y
48 - 1
FG3-2974-000 36 - 2 DIMM ASS’Y
48 - 2
FH4-1402-000 45 - IC34 IC, UPD703107GJ-UEN-025, MCU
FH4-3848-000 32 - IC46 IC, MB87J1762PFVS, ASIC
45 - IC46
FH4-6229-000 36 - IC2 IC, M4A3-32/32-10VC48C91A, PLD
48 - IC2
FH5-3411-000 1 - 11 CD-ROM, PCL/FAX DRIVER
2-11
47 - 1
FH5-3417-000 1 - 12 CD-ROM, NETWORK USER
2-12
49 - 1
FS1-1202-000 21 - 1 BUSHING, 8MM, NYLON (R), OL-10
22 - 1
FS1-1205-000 20 - 1 BUSHING
HB1-3856-000 1 - 1 TRAY, DOCUMENT EXIT
2-1
HB1-3858-030 22 - 2 COVER, READER, LOWER
HB1-3861-000 23 - 1 ARM, BELT TENSION
HB1-3863-000 23 - 2 ARM, HOOK
HB1-3864-000 23 - 3 ARM, DETECTION (DES)
HB1-3868-000 19 - 1 SHAFT, LEFT
HB1-3885-000 21 - 2 ELIMINATOR, STATIC CHARGE
HB1-3887-000 21 - 3 ARM, DOCUMENT PRESSURE
HB1-3902-040 20 - 2 FRAME, READER, UPPER
HB1-3907-000 20 - 3 ARM, SEPARATION ROLLER
HB1-3911-000 24 - 1 ROLLER, PICK-UP
HB1-3915-000 24 - 2 STOPPER, DOCUMENT
HB1-3927-020 22 - 2 COVER, READER, LOWER
HB1-4357-000 1 - 2 LABEL, DESTINATION
2-2
HB1-4394-000 20 - 4 RETAINING RING (E-TYPE)
HB1-4395-000 21 - 4 RETAINING RING
22 - 3
HB1-5163-000 23 - 4 FRAME, READER, LOWER
HB1-5165-000 10 - 1 COVER, TOP
HB1-5171-000 11 - 1 COVER, FACE-UP
HB1-5172-000 3 - 4 COVER, UPPER, LEFT
4-4
HB1-5201-000 31 - 1 PANEL, FRONT
HB1-5209-000 3 - 1 COVER, RIGHT
4-1
HB1-5224-000 43 - 1 STAY, HANDSET HOLDER
HB1-5226-000 28 - 1 COVER, BOTTOM, FEEDER
HB1-5235-000 28 - 2 COVER, BOTTOM, FEEDER, RIGHT
HB1-5236-000 28 - 3 COVER, BOTTOM, FEEDER, LEFT
HB1-5247-000 17 - 1 COVER, ONE TOUCH DIAL 1
HB1-5248-000 17 - 2 COVER, ONE TOUCH DIAL 2
HB1-5249-000 17 - 3 COVER, ONE TOUCH DIAL 3
HB1-5263-000 17 - 4 COVER, SWITCH
HB1-5272-000 11 - 2 COVER, FRONT
HB1-5273-000 8 - 1 COVER, FRONT, RIGHT
HB1-5274-000 18 - 1 STOPPER
HB1-5277-000 16 - 1 TRAY, EXTENSION
HB1-5284-000 24 - 3 ROLLER
HB1-5285-000 21 - 5 ROLLER, DOCUMENT FEED
HB1-5286-000 22 - 4 ROLLER, DOCUMENT FEED
HB1-5287-000 22 - 5 ROLLER, DOCUMENT EJECT
HB1-5298-000 21 - 6 ROLLER, SEPARATION (LOWER)
HB1-5299-000 20 - 5 COVER, UPPER
HB1-5300-000 20 - 6 COVER, DOCUMENT SIZE
HB1-5303-000 20 - 7 ARM, DETECTION (DS/DWS)
HB1-5305-000 20 - 8 ARM, DETECTION (DFS)
HB1-5306-000 21 - 7 COVER, READER, MIDDLE
HB1-5307-000 19 - 2 SHAFT, RIGHT
HB1-5308-000 23 - 5 SHAFT, BELT TENSION ARM
HB1-5310-000 20 - 6 COVER, DOCUMENT SIZE
HB1-5312-000 10 - 2 COVER, CARTRIDGE
HB1-5313-000 3 - 2 COVER, LEFT
4-2
HB1-5316-000 21 - 8 FRAME, READER, MIDDLE
HB1-5325-000 41 - 1 PANEL, FRONT
HB1-5326-000 38 - 1 COVER, FRONT
HB1-5327-000 38 - 2 COVER, LEFT
HB1-5328-000 38 - 3 COVER, RIGHT
HB1-5330-000 5 - 1 COVER, REAR, RIGHT
HB1-5333-000 31 - 2 LABEL, ATTENTION
HB1-5334-000 41 - 2 LABEL, ATTENTION
HB1-5337-000 47 - 2 SPONGE
HB1-5340-000 1 - 3 LABEL, ATTENTION
2-3
37 - 2
42 - 2
HB1-5371-000 11 - 20 EMBLEM
HB1-5372-000 11 - 20 EMBLEM
HB1-5373-000 11 - 20 EMBLEM
HF5-0648-000 12 - 1 PAPER FEED ROLLER UNIT
HF5-0651-000 30 - 1 FEEDER DRIVE GEAR UNIT
HF5-0654-000 21 - 9 WHITE REFERENCE SHEET UNIT
HF5-0658-000 9 - 1 COVER, FRONT, RIGHT
HG1-4365-000 8 - 2 NCU PCB ASSEMBLY
9-2
44 - 1
HG5-1840-000 6 - 2 SPEAKER UNIT
7-2
HG5-2814-000 6 - 3 OPERATION PANEL ASS’Y
7-3
HG5-2817-000 11 - 3 REAR COVER ASS’Y
HG5-2819-000 11 - 4 PRINTER DRIVE ASS’Y
HG5-2820-000 10 - 3 TOP COVER UNIT
