Canon LASER CLASS 710 - 1.3 Moving the Fax Unit

LASER CLASS 730i/720i/710 Chapter 5: Appendix
5-2
1.3 Moving the Fax Unit
Before moving the fax machine, disconnect the power cord and the telephone line; then, take
out the recording paper cassette. Be sure to work in a group of two; one with his/her hands in
the cassette slots, and the other with his/her hands in the grips (recesses in the external cover)
on both sides of the fax machine.
If the fax machine is fitted with a 500-sheet cassette feeder, be sure to relocate it separately
form the fax machine.
The 500-sheet cassette feeder is not secured in place with screws. Do not try
to lift it. Be sure to separate it from the fax machine before relocation.
Figure 5-1 How to Lift the Fax Unit
