LASER CLASS 730i/720i/710 5.GUIDE TO REPLACEMENT
5. GUIDE TO REPLACEMENT
5-1
FIGURE 3-a FIGURE 3-b
FIGURE 6-a
See Page
2-5/7
See Page
2-5/7
Be sure to remove the stopper first as shown before open-
ing the upper/middle frame ass’y.
While freeing the claw, detach the left cover.
FIGURE 9-a
See Page
2-11/13
See Page
2-17
Be sure to route the cable as shown.
When connecting the flat cable to the connector J2 of the
SCNT board, face up the white flat cable surface, and con-
nect the core side of the flat cable to the SCNT board.
SCNT board
Connector J2
To connector J2
Core
White surface
