LASER CLASS 730i/720i/710 Chapter 1: General Description
1-10
Printing range
Item A4 Letter Legal
Effective printing width 8.03" ±0.08 8.27" ±0.08 8.27" ±0.08
(204±2.1 mm) (210±2.1 mm) (210±2.1 mm)
Effective printing length 11.38" ±0.11" 10.69" ±0.11" 13.69" ±0.14"
(289.0 ±2.9 mm) (271.4 ±2.7 mm) (347.6 ±3.5 mm)
Left margin 0.12" ±0.10" 0.12" ±0.10" 0.12" ±0.10"
(3.0 ±2.5 mm) (3.0 ±2.5 mm) (3.0 ±2.5 mm)
Right margin 0.12" ±0.18" 0.12" ±0.18" 0.12" ±0.18"
(3.0 ±4.6 mm) (3.0 ±4.6 mm) (3.0 ±4.6 mm)
Top margin 0.12" ±0.08" 0.12" ±0.08" 0.12" ±0.08"
(3.0 ±2.0 mm) (3.0 ±2.0 mm) (3.0 ±2.0 mm)
Bottom margin 0.20" ±0.19" 0.20" ±0.19" 0.20" ±0.22"
(5.0 ±4.9 mm) (5.0 ±4.7 mm) (5.0 ±5.5 mm)
Figure 1-2 Printing Range
Paper trailing edge
PRINTING RANGE
PRINTING DROP OUT RANGE
Right marginLeft margin
Top margin
Bottom margin
Effective scanning width
Paper leading edge
Effective scanning length
