LASER CLASS 730i/720i/710 Chapter 4: Maintenance and Service
4-120
a-7) Service activity report
The ERROR TX REPORT includes appended service error codes and an error dump list.
In user data “REPORT SETTINGS”, when the “REPORT WITH TX IMAGE” is set to
“ON” in the “TX REPORT”, a section of the first page of transmitted image data is
appended when memory transmission is done
Figure 4-64 Service Error Activity Report
NOTE
When an error occurs with direct transmission, *6 to *12 will not be listed
even if the other party's machine has a V.34 modem.
*1
*2
*3
*4
*5
*6
*7
*8
*9
*10
*11
*12
*13
*14
*15
*16
*17
*18
*19
*20
*21
*22
