LASER CLASS 730i/720i/710 Chapter 1: General Description
1-18
Figure 1-5 External View (3)
Rear View
Face-Up Tray
Holds printed documents after they are ejected
from the machine.
Power Socket
Connect the power cord here.
Lifting Handle
Grip the machine here and on the opposite side
to lift the machine.
Telephone Line Jack (L2)
Connect an additional telephone line here, after
installation of the optional Dual-line Upgrade Kit III
for the LASER CLASS 700 Series.
Telephone Line Jack (L1)
Connect the telephone line here.
Handset Jack
Connect the optional handset or an extension
telephone.
6
5
4
3
2
1
6
5
4
3
2
1
