2-6
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
3- 1 HB1-5209-000 1 COVER, RIGHT
2 HB1-5313-000 1 COVER, LEFT
3 XA9-1262-000 5 SCREW, M4X10
4 HB1-5172-000 1 COVER, UPPER, LEFT
5 XB6-7300-607 1 SCREW, TP, M3X6
