2-20
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
10- 1 HB1-5165-000 1 COVER, TOP
2 HB1-5312-000 1 COVER, CARTRIDGE
3 HG5-2820-000 1 TOP COVER UNIT
4 XA9-1262-000 4 SCREW, M4X10
5 XB1-2300-807 4 SCREW, CROSS-RECESS, FCH
6 XB2-7300-607 1 SCREW, M3X6
7 XB4-7401-209 2 SCREW, BINDING HEAD, SELF-TPG
