2-22
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
11- 1 HB1-5171-000 1 COVER, FACE-UP
2 HB1-5272-000 1 COVER, FRONT
3 HG5-2817-000 1 REAR COVER ASS’Y
4 HG5-2819-000 1 PRINTER DRIVE ASS’Y
5 RB2-3036-000 1 TRAY, PAPER PICK-UP
6 RB2-3037-000 1 TRAY, SUB
7 RB2-6405-000 1 HINGE, LEFT
8 RB2-6406-000 1 HINGE, RIGHT
9 RB2-6285-000 1 GUIDE, PAPER REAR
10 RB2-6287-000 1 TRAY, FACE-UP
11 RB2-6288-000 2 ROLLER, GUIDE
12 RB2-6289-000 2 SPRING, TORSION
13 RG5-5576-000 1 MULTI-PURPOSE TRAY ASS’Y
14 HH7-2687-000 1 MOTOR
15 RH7-1463-000 1 FAN
16 RS6-2030-000 2 SPRING, TENSION
17 XA9-1262-000 9 SCREW, M4X10
18 XB2-7300-607 3 SCREW, M3X6
19 XB6-7300-407 3 SCREW, TP, PH M3X4
20 HB1-5371-000 1 EMBLEM LASER CLASS 710
HB1-5372-000 1 EMBLEM LASER CLASS 720i
HB1-5373-000 1 EMBLEM LASER CLASS 730i
