2-24
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
12- 1 HF5-0648-000 1 PAPER FEED ROLLER UNIT
2 HG5-2824-000 1 CABLE UNIT
3 HG5-2826-000 1 LASER/SCANNER UNIT
4 HG5-2827-000 1 FD DELIVERY ROLLER ASS’Y
5 HG5-2828-000 1 FD DELIVERY ROLLER ASS’Y
6 RG5-5548-000 1 REVERSE GUIDE ASS’Y
7 RG5-5552-000 1 DUPLEX SOLENOID ASS’Y
8 RG5-5559-000 1 FIXING ASS’Y
9 RH2-5427-000 1 FLAT CABLE, LASER
10 RH7-5270-000 1 SOLENOID
11 RH7-5273-000 1 SOLENOID
12 RH7-6051-000 1 MICROSWITCH
13 RS6-0441-000 1 GEAR, 15T
14 RS6-2375-000 4 SPRING, COMPRESSION
15 XA9-1262-000 5 SCREW, M4X10
16 XA9-1273-000 4 SCREW, TP, M4X12
17 XA9-1292-000 2 SCREW, M4X14
18 XB2-7300-607 3 SCREW, M3X6
19 NPN 1 ECU ASS’Y
20 HG5-2832-000 1 FD DELIVERY ROLLER ASS’Y
21 RG5-5542-000 1 FD DELIVERY ROLLER ASS’Y
