2-26
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
13- 1 HG5-2823-000 1 FEED ROLLER UNIT
2 RB2-6249-000 1 HINGE, FEED GUIDE
3 RG5-5553-000 1 POSITION GUIDE ASS’Y
4 RG5-5554-000 N 1 DUPLEX FEED GUIDE ASS’Y
5 XA9-1262-000 7 SCREW, M4X10
6 NPN 1 EPU ASS’Y
