2-28
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
14- 1 RB2-2836-000 1 LEVER, SENSOR
2 RB2-2837-000 1 SPRING, TORSION
3 RB2-2900-000 1 ROLLER, PICK-UP
4 RB2-2904-000 2 ROLLER
5 RB2-3040-000 1 GEAR, 26T
6 RB2-3043-000 1 BUSHING, LEFT
7 RB2-3044-000 1 BUSHING, RIGHT
8 RB2-6248-000 1 DAMPER, ASS’Y
9 RF5-3272-000 1 PAD, SEPARATION
10 RG5-4128-000 1 MP PICK-UP ASS’Y
11 RG5-4156-000 1 CASSETTE PICK-UP GEAR ASS’Y
12 RG5-5551-000 1 CASSETTE PAPER PICK-UP ASS’Y
13 RS6-0445-000 1 GEAR, 14T
14 RS6-2025-000 1 SPRING, TENSION
15 WG8-5364-000 1 IC,PHOTO-INTERRUPTER,GP1SQ73P
16 XA9-1262-000 5 SCREW, M4X10
