Canon LASER CLASS 710 - Page 344

2-30
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
15- 1 HG5-2821-000 1 REGISTRATION ROLLER UNIT
2 HG5-3097-000 1 CABLE UNIT
3 RB2-2843-000 1 SPRING, TORSION
4 RB2-2926-000 1 BUSHING, TRANSFER, RIGHT
5 RB2-3073-000 1 SHAFT, DRIVE, 1
6 RB2-6264-000 1 ARM, SENSOR
7 RB2-6268-000 2 PULLEY
8 RB2-6269-000 1 SHAFT, DRIVE, FRONT
9 RB2-6270-000 2 BELT, PAPER FEED, 3
10 RB2-6272-000 1 BELT, PAPER FEED, 1
11 RB2-6273-000 2 BELT, PAPER FEED, 2
12 RB2-6274-000 2 SHAFT, DRIVE, REAR
13 RG5-5550-000 1 TRANSFER ROLLER ASS’Y
14 RG5-5577-000 1 GEAR ASS’Y
15 RS6-0464-000 1 GEAR, 20T
16 RS6-2022-000 1 SPRING, COMPRESSION
17 WG8-5364-000 1 IC,PHOTO-INTERRUPTER,GP1SQ73P
18 XA9-1262-000 3 SCREW, M4X10
