Canon LASER CLASS 710 - Page 348

2-34
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
17- 1 HB1-5247-000 1 COVER, ONE TOUCH DIAL 1
2 HB1-5248-000 1 COVER, ONE TOUCH DIAL 2
3 HB1-5249-000 1 COVER, ONE TOUCH DIAL 3
4 HB1-5263-000 1 COVER, SWITCH
5 HG5-3069-000 1 OPCNT BOARD ASS’Y
6 HH4-3198-000 1 IC, BU12306-04, C-MOS
7 HH7-2683-000 1 LCD UNIT
8 XB4-7300-807 22 SCREW, TAP TIGHT, BINDING HEAD
