Canon LASER CLASS 710 - Page 350

2-36
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
18- 1 HB1-5274-000 1 STOPPER
2 XB1-2300-807 2 SCREW, CROSS-RECESS, FCH
3 NPN 1 UPPER/MIDDLE FRAME ASS’Y
4 NPN 1 LPWER READER FRAME ASS’Y
