2-40
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
20- 1 FS1-1205-000 2 BUSHING
2 HB1-3902-040 1 FRAME, READER, UPPER
3 HB1-3907-000 1 ARM, SEPARATION ROLLER
4 HB1-4394-000 1 RETAINING RING (E-TYPE)
5 HB1-5299-000 1 COVER, UPPER
6 HB1-5300-000 1 COVER, DOCUMENT SIZE LASER CLASS 730i/710
HB1-5310-000 1 COVER, DOCUMENT SIZE LASER CLASS 720i
7 HB1-5303-000 2 ARM, DETECTION (DS/DWS)
8 HB1-5305-000 1 ARM, DETECTION (DFS)
9 HG5-2874-000 1 SEPARATION MOTOR ASS’Y
10 HG5-2859-000 1 SEPARATION ROLLER ASS’Y(UPPER)
11 HG5-3066-000 1 SENSOR BOARD ASS’Y
12 HS5-0372-000 1 GEAR, 29T/22T
13 HS5-0373-000 1 GEAR, 25T/22T
14 HS5-2184-000 1 SPRING
15 HS5-2185-000 2 SPRING
16 HS5-6086-000 2 ROLLER, BACK UP
17 XA9-0476-000 1 SCREW, TP M3X8
18 XB1-2300-807 1 SCREW, CROSS-RECESS, FCH
19 XB4-7300-807 2 SCREW, TAP TIGHT, BINDING HEAD
20 XB4-7301-209 4 SCREW, SELF-TAPPING
21 XB4-7400-607 1 SCREW, SELF-TAPPING, PANHEAD
