2-63
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
IC34
IC46
IC12
IC1
IC2
IC43
BAT1
BAT2
IC16
1
1
FIGURE 32
SCNT BOARD ASS’Y
