Components Guide
MVX 460/MVX 450/MVX 430
Lens Cover Switch ( 27, 30)
( - open, - closed)
Grip belt ( 19)
CARD access indicator ( 30) /
CHARGE indicator ( 14)Battery attachment unit ( 14)
Serial number Memory card slot ( 18)/ Backup battery
compartment ( 22)BATTERY RELEASE button ( 14)
DV terminal ( 85, 89, 92, 104) Terminal cover
USB terminal ( 97, 106) DC IN terminal ( 14)
Left side view
Right side view
