6
3. Move throttle lever to [High speed] position to increase the
engine speed.
4. Move auxiliary (aux.) transmission shift lever to [Low speed]
position.
5. To accelerate, move drive lever slowly.
Moving forward : Push drive lever to the front.
Moving backward : Push drive lever to the rear.
Shifting
6. When shifting is needed, stop and move auxiliary (aux.)
transmission shift lever to [High] or [Low] position.
Always stop machine to shift. Shifting while
travelling may damage transmission.
– 20 –
Operation
6.3 Driving
1. Check the area around machine for safety.
2. Release parking brake lock lever.
Parking brake
lock lever
Throttle lever
High
speed
Low speed
Aux. transmission
shift lever
Drive lever
Forward
Backward
Low speed
High speed
Aux. transmission
shift lever
To Next Page
